120001
by Racal-milgo Electronics Corp
- Nsn:
- 1680008252851
- Description:
- The miConverter Gx is a miniature 1000BASE-T UTP copper to 1000BASE-X fiber Gigabit Ethernet media converter. The miConverter Gx provides cost-effective fiber connectivity from Gigabit switches to diagnostic equipment, desktop and laptop computers.The miConverter Gx is the first Gigabit media converter powered by a USB port (1.0, 1.1, and 2.0). An optional USB Power Adaptor Cable is available, which reduces the module's weight and eliminates the need to tether the miConverter Gx to an electrical outlet.Miniature Gigabit Ethernet media converterSupports 1000BASE-T, 1000BASE-X and the IEEE 802.3 specificationPlug-and-Play capabilityUSB power via optional Power Adapter CableSupports Full/Half-Duplex fiber optic auto-negotiationMultimode and single-mode fiber optionsLED indicators for UTP and fiber statusDomestic, Universal and Country/Region specific power supply optionsWall-mount with optional mounting brackets or included Velcro® stripsSmall and lightweight, only 5 ounces (without power supply)Cost-effectiveLifetime Warranty and free 24/7 Technical Support
Contact Info:
Phone
(817) 672-7657
Email
equipment@makttrans.com
Interfaces/Ports
- USB
- No
- DVI
- No
- Number of Network (RJ-45) Ports
- 1
- Network (RJ-45)
- Yes
- Parallel Port
- No
- Management Port
- No
- Digital Audio
- No
- Number of ST Ports
- 1
- Digital Audio/Video
- No
- Total Number of Ports
- 2
- ST Port Type
- Duplex
General Information
- Product Type
- Transceiver/Media Converter
- Manufacturer Part Number
- 1200-0-1
- Manufacturer Website Address
- http://www.omnitron-systems.com
- Manufacturer
- Omnitron Systems
- Product Model
- 1200-0-x
- Product Name
- miConverter Gx ST Multimode 550m US AC Powered
- Package Type
- Retail
- Product Line
- miConverter
- Product Series
- Gx
- Brand Name
- Omnitron Systems
Media & Performance
- Maximum Distance Supported
- 1804.46 ft
- Media Type Supported
- Optical Fiber
- Fiber Mode Supported
- Multi-mode
- Fiber Optic Wavelength
- 850 nm
Miscellaneous
- Additional Information
- Input Voltage:5-15VDC via 2.5mm barrel (0.2A @ 9VDC)100-120VAC/60Hz (0.03A @ 120VAC)
- Package Contents
- miConverter Gx ST Multimode 550m US AC Powered US Power Supply - 120Volt / 60Hz Velcro Strip User Manual
- Certifications & Standards
- EIA/TIA 568A/B Compliance: UL CE FCC Class A IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X
- Country of Origin
- United States
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- WEEE
Network & Communication
- Network Technology
- 1000Base-SX
- Ethernet Technology
- Gigabit Ethernet
Physical Characteristics
- Weight (Approximate)
- 5 oz
- Form Factor
- Wall Mountable
- Height
- 0.8"
- Width
- 1.7"
- Depth
- 4.1"
Power Description
- Input Voltage
- 120 V AC
