PD-9501GO/AC
by Microsemi
110 V AC, 220 V AC Input - 55 V DC Output - 60 W
- Unspsc:
- 39121004
- Upc:
- 844117001983
- Description:
- The single-port PD-9501GO delivers up to 60W of power over Ethernet along with surge protection for both the AC and the PoE ports ensuring the indoor equipment is protected from outdoor surges.
Interfaces/Ports
- Input Ports
- 1 10/100/1000Base-T
- Output Ports
- 1 10/100/1000Base-T
General Information
- Product Type
- PoE Injector
- Manufacturer Part Number
- PD-9501GO/AC
- Manufacturer Website Address
- http://www.microsemi.com
- Manufacturer
- Microsemi Corporation
- Product Model
- 9501GO
- Product Name
- Outdoor 1-Port, 60W, 10/100/1000 BaseT Midspan, AC Input
- Brand Name
- Microsemi
Miscellaneous
- Compatibility
- Wireless LAN Access PointsSecurity Network CamerasIP Terminals
- Certifications & Standards
- IEEE802.3at CompliantIEEE 802.3af CompliantCEFCC Part 15, Class BEN 55022 Class BEN 55024, EN61000-4-5 Class 5 (6kV CM)VCCIUL60950-1UL60950-22GS MarkEN60529, Level 1P66NEMA 250, Level 4XASTM B-117
- Country of Origin
- Philippines
- Green Compliant
- Yes
- Green Compliance Certificate/Authority
- WEEE
Physical Characteristics
- Weight (Approximate)
- 1.65 lb
Power Description
- Input Voltage
- 220 V AC
- Maximum Frequency
- 60 Hz
- Maximum Input Current
- 2 A
- Maximum Output Power
- 60 W
- Maximum Output Voltage
- 55 V DC
