1754D1X
by Lenovo
16 Computer(s) - 2 Local User(s) - 2 Remote User(s) - 1680 x 1050 - 3 x Network (RJ-45) - 4 x USB - Rack-mountable - 1U
- Unspsc:
- 43211601
- Upc:
- 74000018334
- Description:
- The IBM Global 2X2X16 Console Manager (GCM16) and IBM Global 4X2X32 Console Manager (GCM32) are the next generation digital keyboard-video-mouse (KVM) console managers that provide KVM-over-IP and serial console management technology in a single appliance. Either console lets you access and manage all servers remotely, even to the system BIOS, using your existing IP infrastructure. The GCM16 has 16 target ports and supports up to 2 local users and 2 remote users, and the GCM32 has 32 target ports and supports up to 2 local users and 4 remote users. Figure 1 shows these two models.
Interfaces/Ports
- USB
- Yes
- Number of Network (RJ-45) Ports
- 3
- Network (RJ-45)
- Yes
- Number of USB Ports
- 4
General Information
- Product Type
- KVM Switchbox
- Manufacturer Part Number
- 1754D1X
- Manufacturer Website Address
- http://www.lenovo.com/us/en/
- Manufacturer
- Lenovo Group Limited
- Product Model
- GCM16
- Product Name
- GCM16 KVM Switch
- Brand Name
- Lenovo
Miscellaneous
- Package Contents
- GCM16 KVM SwitchMounting Hardware1 x 1U Filler Panel2 x C13/C14 Rack Power CablesRJ45-DB9F DCE AdapterRJ45-DB9M DTE Adapter16 TerminatorsInstallation Publications and Warranty
Physical Characteristics
- Weight (Approximate)
- 7 lb
- Form Factor
- Rack-mountable
- Rack Height
- 1U
- Height
- 1.7"
- Width
- 17"
- Depth
- 9.2"
Power Description
- Input Voltage
- 110 V AC
Technical Information
- Number of Computers Supported
- 16
- Number of Local Users Supported
- 2
- Number of Remote Users Supported
- 2
- Daisy Chain Supported
- Yes
Video
- Maximum Video Resolution
- 1680 x 1050
- Graphic Mode
- WSXGA+
